SPECIFICATIONS



12-watt Transmitter Specifications


Trace mode frequencies

2220M 8 kHz, 82 kHz

2250M/2273M 577 Hz, 8 kHz, 33 kHz, 200 kHz

2250ME/2273ME (International) 577 Hz, 8 kHz, 33 kHz, 133 kHz

Fault mode frequencies

10/20 Hz -fault

577 Hz / 33 KHz -trace

Induction mode frequencies

2220M 8 kHz, 82 kHz

2250M/2273M 8 kHz, 33 kHz, 200 kHz

2250ME/2273ME (International) 8 kHz, 33 kHz, 133 kHz

Pulsing tone frequencies

2220M n/a

2250M/2273M 577 Hz, 200 kHz

2250ME/2273ME (International) 577 Hz, 133 kHz

Output power (maximum)

3 watt maximum

12 watt w/external DC source(varies by frequency)

Output voltage (maximum) 70 Vrms

Output Protection 240 Vrms

Weight w/batteries (alkaline) 5.2 lbs (2.4 kg)

Battery Quantity and size 6 "C" alkaline (LR14)

Battery Life 40 hours typical (normal output level) 10 hours typical (high output level) Rechargeable battery will extend operation time by 40%

External DC power 9–18 V DC

Standard IP54

Regulatory CE, FCC

Operating Temperature -4°F to 122°F (-20°C to 50°C)

Storage Temperature -4°F to 158°F (-20°C to 70°C)
